Please note due to a change of branding, your order may be fulfilled with FIBARO branded products. Please be assured they are identical to Nice.
Nice Smart-Control is a small, easy-to-install device that makes standard devices smart! Nice Smart-Control is the perfect and cost-effective solution for anyone wanting to add alarm systems or sensors, thermostats, gates or rolling shutters to their smart home.
It allows to enhance the functionality of wired sensors and other devices by adding Z-Wave network communication.
You can connect binary sensors, analog sensors, DS18B20 temperature sensors or DHT22 humidity and temperature sensor to report their readings to the Z-Wave controller.
It can also control devices by opening/closing output contacts independently of the inputs.
Features
- Only compatible with a Nice or FIBARO gateway (Home Center 2, 3 or Lite, Yubii Home Pro or Yubii Home) for full functionality
- Supports Z-Wave network Security Modes: S0 with AES-128 encryption and S2 Authenticated with PRNG-based encryption.
- Works as a Z-Wave signal repeater.
-
Allows for connecting sensors:
- 6 DS18B20 sensors,
- 1 DHT sensor,
- 2 2-wire analog sensor,
- 2 3-wire analog sensor,
- 2 binary sensors.
- Built-in temperature sensor.
Specifications
| Power supply | 9-30V DC ±10% |
| Inputs |
2 0-10V or digital inputs 1 serial 1-wire input |
| Outputs | 2 potential-free outputs |
| Supported digital sensors | 6 DS18B20 or 1 DHT22 |
| Maximum current on outputs | 150mA |
| Maximum voltage on outputs | 30V DC / 20V AC ±5% |
| Built-in temperature sensor measurement range |
-55°C–126°C (-67°F–259°F) |
| Operating temperature | 0–40°C (32–104°F) |
| Radio protocol | Z-Wave (500 series chip) |
| Radio frequency |
868.4 or 869.8 MHz EU; 908.4, 908.42 or 916.0 MHz US; 921.4 or 919.8 MHz ANZ; 869.0 MHz RU; |
| Radio ransmit power | max. 7 dBm (EIRP) |
| Range |
up to 50m (164 ft) outdoors up to 40m (131 ft) indoors (depending on terrain and building structure) |
|
Dimensions (Length x Width x Height) |
29 x 18 x 13 mm (1.14” x 0.71” x 0.51”) |
| Compliance with EU directives |
RoHS 2011/65/EU RED 2014/53/EU |
Manuals
