Nice
Yubii Home Pro
Yubii Home Pro
Whitehills
15 Olympic Court
Blackpool FY4 5GU
United Kingdom
Choose options
Simply the 'brains' for your smart home. The Yubii Home Pro (formally known as the FIBARO Home Center 3) connects all your devices together and allows their operation to be programmed and controlled remotely via the dedicated Yubii App from anywhere in the world.
Yubii Home Pro is the core element of the Nice system.
It enables the integration of smart home devices into a single system to provide convenient control and a powerful automation platform. The gateway is now even more secure, reliable, and versatile.
It is super easy to set up and configure your Yubii Home Pro but if you prefer some help or simply want to save time then why not select our Pre-Configuration Service which configures your Yubii Home Pro and any smart devices you purchase from us so that you simply need to install them and away you go. You must order your Yubii Home Pro, smart devices and our Pre-Configuration Service at the same time.
Features
- Provides a reliable foundation for Nice system.
-
Capable of controlling all Nice and other compatible devices using the following radio standards:
- Z-Wave (500 series)
- Wi-Fi – 2.4 GHz and 5 GHz (802.11 b/g/n/a/ac)
- Nice FLOR, OPERA and PLN2+
- No Internet cable required, works also on Wi-Fi
- Modern interface designed for ease of use
- Enhanced and convenient scene editor
- Support for more advanced apps and drivers
- May be used with all devices certified with the Z-Wave Plus certificate and should be compatible with such devices produced by other manufacturers
Specifications
General information
Model | YHP-001 |
CPU | Quad-core Arm Cortex A53 (1.2GHz) |
RAM | RAM 2GB LPDDR3 |
Flash memory | 8GB eMMC |
Power supply | 12V DC (adapter included) |
Operating temperature | 0-40°C |
Operating humidity | max. 75% relative humidity (non-condensing) |
Network interface | 10/100 (Base-T) Ethernet via RJ45 connector |
USB | 1 (2.0) |
Power connector | barrel connector 5.5mm x 2.5mm (female) |
Dimensions | 220x140x35 mm |
Radio Communication
Protocol | Radio frequency band | Max. transmitting power | |
Z-Wave
(500 series) |
EU |
868.0-868.6 MHz 869.7-870.0MHz |
+14dBm |
AU, NZ, CL | 920-925Mhz | +5dBm | |
BR | 920-925Mhz | -2dBm | |
THA | 920-925Mhz | +7dBm | |
Wi-Fi
(802.11 b/g/n/a/ac) |
2.4GHz | 2400-2483MHz | +20dBm |
5GHz | 5150-5250MHz | +14dBm | |
433Mhz | EU, THA | 433.05-434.04Mhz | +10dBm |
AU, NZ, CL, BR | 433.05-434.04Mhz | +14dBm | |
868Mhz | EU | 868.0-869.65MHz | +10dBm |
Yubii Home is the core element of the Yubii smart home system.
It enables the integration of smart home devices into a single system to provide convenient control and a powerful automation platform. The
gateway is now even more secure, reliable, and versatile.
